LCD12864 SHIELD FOR ARDUINO DFROBOT

This framed LCD12864 Shield with LED backlight is compatible with most of Arduino controllers and supports English/Chinese/Picture display. With 5 analog extension pins and 8 digital pins, the LCD12864 Shield also integrates a 5-key joystick for controlling additional functions, making it an ideal module for prototyping and interactive projects.

• Power supply: 3.3V
• Pin used: D7, D8, D9, D10, D11, D13, A0
• Reset button
• 5 degree joystick (using Arduino Analog Pin 0)
• Backlit control (using Arduino Digital Pin 7)
• Extra 5 Analog pins & 8 Digital pins
• Size:60x55x20mm

• LCD12864 Shield  (1 unit)

• Wiki Doc
• DFR0287_Schematic_V1
• U8glib library For Arduino
• DFR0287_SampleCode_V1

Tools

• Bitmap Converter
